Description

Powerful LED highbay lighting for your workspace

The LED Highbay Gen 5 offers a reliable lighting solution designed for industrial and commercial areas where strong, energy-efficient illumination is needed. With its 150W power input, high 26250 lumens output, and cool 4000K light color, you enjoy bright and uniform lighting. The robust aluminium housing in Black ensures durability, while the IP66 rating guarantees resistance against dust and water, making it perfect for demanding environments.

Why this LED highbay works for you

If you need powerful lighting that reduces maintenance costs, this fixture is an excellent choice. It comes with a 70D beam angle for controlled light distribution and features 1-10V dimming capability, giving you full control over brightness when needed. With its modern Gen 5 design, it’s both efficient and versatile.

Key features and benefits

  • LED Highbay Gen 5 Black Aluminium 150W 4000K with 26250 lumens delivers extremely bright and consistent illumination for large areas.
  • IP66 protection ensures optimal performance in dusty, humid, or wet locations.
  • Durable aluminium housing in Black provides long-lasting strength and a sleek appearance.
  • 1-10V dimmable driver lets you adjust brightness to suit changing lighting needs.
  • 70D beam angle enhances uniform coverage without wasting energy.
  • 4000K cool white light ensures a clear, comfortable working atmosphere.
  • EAN 4058075844308 helps with easy product identification and ordering.

Where you can use this LED highbay

This LED Highbay is ideal for warehouses, factories, workshops, gymnasiums, and retail spaces with high ceilings. Wherever you need a reliable LED lighting solution for large spaces, it provides energy savings and dependable performance.

Specifications

General Information

Product Name
HB P 150W 840 70DEG IP66 PS
Product Family
HIGH BAY GEN 5
Brand
LEDVANCE
Product Code
4058075844308

Electrical Ratings

Wattage
150 W / 125 W
Voltage
220-240 V
Mains Frequency
50-60 Hz
Nominal Current
665-555 mA
Power Factor
> 0.95
Total Harmonic Distortion
< 15%
Protection Class
I
Inrush Current
16.7 A
Inrush Current Time Th50
302 µs
Driver Type
Integrated LED driver
Circuit Breaker Load
Max Luminaires per B16 Breaker
13
Max Luminaires per C10 Breaker
10
Max Luminaires per C16 Breaker
16

Photometrical Data

Luminous Flux
26250 lm / 21875 lm
Luminous Efficacy
175 lm/W
Color Temperature
4000 K
Light Color
Cool White
Color Rendering Index (CRI)
≥80
Standard Deviation of Color Matching (SDCM)
≤4 sdcm
Beam Angle
70°
Low Flicker
Yes
Flickering Metric (Pst LM)
<1
Stroboscope Effect Metric (SVM)
<0.4
Photobiological Safety Group
RG1

Physical Attributes

Product Weight
2.9 kg
Body Material
Aluminum
Cover Material
Polycarbonate (PC)
Product Color
Black
Housing Color
Black
RAL Color
RAL 9005
Dimensions
Diameter
321 mm
Height
160 mm
Cable Length
1500 mm

Operating Conditions

Ambient Temperature Range
-30°C to 50°C
Storage Temperature Range
-40°C to 80°C
Application Environment
Indoor
Mounting Type
Surface / Suspended
Mounting Location
Ceiling / Wall

Durability and Safety

IP Rating
IP66
IK Rating
IK10
Lifespan L70/B50 at 25°C
120000 h
Lifespan L80/B10 at 25°C
100000 h
Lifespan L80/B50 at 25°C
100000 h
Lifespan L90/B10 at 25°C
49000 h
Switching Cycles
200000
Glow Wire Test
850 °C
Mercury Content
0.0 mg
Limited Surface Temperature (D sign)
Yes
Ball Shot Safe
No
Light Source Included
Yes
Replaceable Light Source
No

Control and Features

Dimmable
Yes
Dimming Interface
0-10V
Special Function
MULTI SELECT (Selectable power steps)
Output Current
615 mA
Output Ripple Current
< 5%

Certifications and Standards

Standards
CE, UKCA, EAC, CB, ENEC, TÜV SÜD, EPD
EPD
LEDV-00032-V01.01-EN

Logistical Data

Packaging Unit
1 piece per shipping box
Gross Weight
3.553 kg
Volume
22.75 dm³
Packaging Dimensions
Length
368 mm
Width
368 mm
Height
168 mm
